A-Series Pitch 0.5
- Pitch 0.5mm, 04~40 pin
- SMT Type (With Holder)
- Dim.: 04~30pin:〔(Pin*0.5)+2.0〕L x 3.00 W x 0.98 H mm
- Dim.: 31~40pin:〔(Pin*0.5)+2.0〕L x 3.30 W x 0.98 H mm
- FPC/FFC Thickness: 0.30 mm
- Operation: Horizontal, Bottom Contact Type
- Front ZIF Type
- Pitch 0.5mm, 04~60pin
- SMT Type (With Holder)
- Dim.:〔(Pin*0.5)+3.4〕L x 5.80 W x 2.00 H mm
- FPC/FFC Thickness: 0.30 mm
- Operation: Horizontal, Bottom Contact Type
- Front ZIF Type
- Pitch 0.5mm, 04~60pin
- SMT Type (With Holder)
- Dim.:〔(Pin*0.5)+3.4〕L x 5.80 W x 2.00 H mm
- FPC/FFC Thickness: 0.30 mm
- Operation: Horizontal, Bottom Contact Type
- Front ZIF Type
- Pitch 0.5mm, 04~53 pin
- SMT Type (With Holder)
- Dim.:〔(Pin*0.5)+4.4〕L x 4.10 W x 1.50 H mm
- FPC/FFC Thickness: 0.30 mm
- Operation: Horizontal, Bottom Contact Type
- Front ZIF Type
- Pitch 0.5mm, 04~65 pin
- SMT Type (With Holder)
- Dim.:〔(Pin*0.5)+6.5〕L x 4.80 W x 2.00 H mm
- FPC/FFC Thickness: 0.30 mm
- Operation: Horizontal, Top Contact Type
- Slider Type
- Pitch 0.5mm, 04~65 pin
- SMT Type (With Holder)
- Dim.:〔(Pin*0.5)+6.5〕L x 4.80 W x 2.00 H mm
- FPC/FFC Thickness: 0.30 mm
- Operation: Horizontal, Top Contact Type
- Slider Type
- Pitch 0.5mm, 04~40 pin
- SMT Type (With Holder)
- Dim.:〔(Pin*0.5)+4.9〕L x 6.15 W x 2.00 H mm
- FPC/FFC Thickness: 0.30 mm, with buckle
- Operation: Horizontal, Bottom Contact Type
- Front ZIF Type
- Pitch 0.5mm, 04~40 pin
- SMT Type (With Holder)
- Dim.:〔(Pin*0.5)+4.9〕L x 6.15 W x 2.00 H mm
- FPC/FFC Thickness: 0.30 mm
- Operation: Horizontal, Bottom Contact Type
- Front ZIF Type
- Pitch 0.5mm, 04~65 pin
- SMT Type (With Holder)
- Dim.:〔(Pin*0.5)+6.5〕L x 4.80 W x 2.00 H mm
- FPC/FFC Thickness: 0.30 mm
- Operation: Horizontal, Bottom Contact Type
- Slider Type
